Superior Design for Shearing Accuracy and Reliability

Features

Accurshear offers outstanding technological advancement in shearing technology with a full line of shears including the precision sheet metal shears and plate shears. Accurshear is the number one selling hydraulic shear in North America with over 5,000 installations. Accurshear consistently scores “very satisfied” for customer satisfaction, reliability, and on-the-job performance.

All Accurshear models are heavy, durable machines rated to shear materials with tensile strengths up to 80,000psi. The shears are of one piece welded construction manufactured in the USA. Accurshears have the lowest rake angles in the industry. This feature along with the box frame construction guarantees the best possible cut with the least camber, twist and bow; and fast cycle times with cycle times up to 40 SPM. The solid machined table is unique in the industry and makes processing of thin materials quick and easy.

Standard features on all shear models:

Manufactured in North America, with North American built quality, Accurpress has 1,000's of press brakes and shears operating in every conceivable precision sheet metal forming and heavy plate fabrication environment. Manufacturer: Accurshear Model Number: 625010 Serial Number: 3535 Model Year: 1999 Size: 1/4″ x 10′ Stock Number: 13149 Category: Shear, Power Squaring Features: SC2 backgauge control (pendant style).

  • 4-edge blades
  • 36” CNC power-operated backgauge with pre-select programs and automatic swing up
  • 4 foot squaring arm
  • Shadow light
  • Manual blade clearance adjustment
  • Oil cooler
  • Adjustable stroke length
  • Pedestal MR CNC control provides you with the most CNC features of any machine on the market. All the buttons are on the front console station, giving you fingertip control over each function. (See control picture above)

Optional features for enhanced productivity:

  • CNC Frontgauge systems
  • Sheet support systems
  • Conveyor stacker systems
  • Front support arms
  • Ball transfers in table and in support arms
  • Power blade clearance
  • T-slots in table.
  • To enhance safety and allow an operator to position smaller pieces of metal into position for shearing, an OHSA and ANSI compliant light curtain is available

With options from 10 gauge to 1″, the line of Accurshears are rated to shear structural quality steel with properties up to 80,000 tensile and 44,000 yield strengths:

6135 Series – 10 gauge

  • Pendant control c/w on/off buttons, mode selector switch, and stroke control dial
  • Backgauge control includes LED display, inch or metric conversion, go-to-position function, 99 pre-select programs, hour meter, and stroke counter
  • 36″ backgauge travel with automatic swing up backstop at full extension
  • 4-edged blades, top and bottom, modified high carbon, high chrome
  • 3 position footswitch control
  • 4′ squaring arm c/w steel rule with 1/16″ and 1mm increments
  • Shadow light and line
  • Hand slots in table
  • Drilled and tapped holes in front of table

6500 Series 1/2″

Manual
  • Pendant control c/w on/off buttons, mode selector switch, and stroke control dial
  • Backgauge control includes LED display, inch or metric conversion, go-to-position function, 99 pre-select programs, hour meter, and stroke counter
  • 36″ backgauge travel with automatic swing up backstop at full extension
  • 4-edged blades, top and bottom, high carbon, shock resisting.
  • 3 position footswitch control
  • 4′ squaring arm c/w steel rule with 1/16″ and 1mm increments.
  • Manual quick blade clearance adjustment on 650010 and 650012 models
  • Power blade clearance on 650014 metal shears and larger models
  • Shadow light and line
  • Hand slots in table
  • T-slot in front of table
  • Ball transfers in table
  • Side frame gaps for slitting purposes
  • Oil cooler
Manual

6250 Series 1/4″
6375 Series 3/8″

  • Pendant control c/w on/off buttons, mode selector switch, and stroke control dial
  • Backgauge control includes LED display, inch or metric conversion, go-to-position function, 99 pre-select programs, hour meter, and stroke counter
  • 36″ backgauge travel with automatic swing up backstop at full extension
  • 4-edged blades, top and bottom, modified high carbon, high chrome
  • 3 position footswitch control
  • 4′ squaring arm c/w steel rule with 1/16″ and 1 mm increments
  • Manual quick blade clearance adjustment
  • Hand slots in table
  • T-slot in front of table
  • Shadow light and line
  • Oil cooler

6625 Series 5/8″
6750 Series 3/4″
61000 Series 1″

  • Pendant control c/w on/off buttons, mode selector switch, and stroke control dial
  • Backgauge control includes LED display, inch or metric conversion, go-to-position function, 99 pre-select programs, hour meter, and stroke counter
  • 48″ backgauge travel with automatic swing up backstop at full extension
  • 4-edged blades, top and bottom, high carbon, shock resisting.
  • 3 position footswitch control
  • 4′ squaring arm c/w steel rule with 1/16″ and 1 mm increments.
  • Power blade clearance adjustment
  • Shadow light and line
  • Hand slots in table
  • T-slot in front of table
  • Ball transfers in table
  • Oil cooler
